NCERT Solutions for Class 9 Maths Chapter 13: Surface Areas and Volumes - Exercise 13.9

Exercise 13.9

1. A wooden bookshelf has external dimensions as follows: Height = \[110  \text{cm}\] , Depth = $25  \text{cm}$, Breadth = \[85  \text{cm}\] (see the given figure). The thickness of the plank is $5  \text{cm}$everywhere. The external faces are to be polished and the inner faces are to be painted. If the rate of polishing is $20$paise per $\text{c}{{\text{m}}^{2}}$and the rate of painting is $10$ paise per $\text{c}{{\text{m}}^{2}}$, find the total expenses required for polishing and painting the surface of the bookshelf.

(Image will be uploaded soon)

Ans:

External length \[\left( l \right)\]of book self\[=85  \text{cm}\].

External breadth $\left( b \right)$of book self\[=\]$25  \text{cm}$.

External height \[\left( h \right)\]of book self\[=\]\[110  \text{cm}\].

(Image will be uploaded soon)

External surface area of shelf while leaving out the front face of the shelf = \[lh\text{ }+\text{ }2\left( lb\text{ }+\text{ }bh \right)\]

\[=\text{ }\left[ 85\text{ }\times \text{ }110\text{ }+\text{ }2\text{ }\left( 85\text{ }\times \text{ }25\text{ }+\text{ }25\text{ }\times \text{ }110 \right) \right]\text{ c}{{\text{m}}^{2}}\]

\[=\text{ }\left( 9350\text{ }+\text{ }9750 \right)\text{ c}{{\text{m}}^{2}}\]

\[=\text{ }19100\text{ c}{{\text{m}}^{2}}\]

Area of front face \[=\text{ }\left[ 85\text{ }\times \text{ }110\text{ }-\text{ }75\text{ }\times \text{ }100\text{ }+\text{ }2\text{ }\left( 75\text{ }\times \text{ }5 \right) \right]\text{ c}{{\text{m}}^{2}}\]

\[=\text{ }1850\text{ }+\text{ }750\text{ c}{{\text{m}}^{2}}\]

\[=\text{ }2600\text{ c}{{\text{m}}^{2}}\]

Area to be polished \[=\text{ }\left( 19100\text{ }+\text{ }2600 \right)\text{ }c{{m}^{2}}\]

\[=\text{ }21700\text{ c}{{\text{m}}^{2}}\]

Cost of polishing \[1\text{ c}{{\text{m}}^{2}}\]area \[=\text{ Rs}.\text{ }0.20\]

Cost of polishing \[21700\text{ c}{{\text{m}}^{2}}\] area Rs. \[\left( 21700\text{ }\times \text{ }0.20 \right)\text{ }=\text{ Rs}.\text{ }4340\]

(Image will be uploaded soon)

It can be observed that length \[\left( l \right)\] , breadth$\left( b \right)$, and height \[\left( h \right)\]of each row of the bookshelf is\[75 \text{cm}\],$20  \text{cm}$ and $30  \text{cm}$ respectively.

Area to be painted in $1$ row \[=\text{ }2\left( l\text{ }+\text{ }h \right)b\text{ }+\text{ }lh\]

\[=\text{ }\left[ 2\text{ }\left( 75\text{ }+\text{ }30 \right)\text{ }\times \text{ }20\text{ }+\text{ }75\text{ }\times \text{ }30 \right]\text{ c}{{\text{m}}^{2}}\]

\[=\text{ }\left( 4200\text{ }+\text{ }2250 \right)\text{ c}{{\text{m}}^{2}}\]

\[=\text{ }6450\text{ c}{{\text{m}}^{2}}\]

Area to be painted in $3$ rows \[=\text{ }\left( 3\text{ }\times \text{ }6450 \right)\text{ c}{{\text{m}}^{2}}\text{ }=\text{ }19350\text{ c}{{\text{m}}^{2}}\]

Cost of the painting \[1\text{ c}{{\text{m}}^{2}}\]area \[=\text{ Rs}.\text{ }0.10\]

Cost of the  painting \[19350\text{ c}{{\text{m}}^{2}}\] area \[=\text{ Rs}.\text{ }\left( 19350\text{ }\times \text{ }0.1 \right)\]

\[=\text{ }Rs.\text{ }1935\]

Total expense required for polishing and painting \[\text{ Rs}.\text{ }\left( 4340\text{ }+\text{ }1935 \right)\]

\[=\text{ }Rs.\text{ }6275\]

 Therefore, the Total expense for  polishing and painting the surface of the bookshelf cost is  \[\text{Rs}\text{. }6275\] .

2. The front compound wall of a house is decorated by wooden spheres of diameter \[21\text{ }cm,\]placed on small supports as shown in the given figure. Eight such spheres are used for this purpose, and are to be painted silver. Each support is a cylinder of radius \[1.5\text{ }cm\]and height \[7\text{ }cm\]and is to be painted black. Find the cost of paint required if silver paint costs \[25\text{ }\] paise per \[\text{c}{{\text{m}}^{2}}\] and black paint costs \[5\] paise per\[\text{c}{{\text{m}}^{2}}\].

(Image will be uploaded soon)

Ans:

Radius (r) of wooden sphere$=\left(\frac{21}{2}\right) \mathrm{cm}=10.5 \mathrm{~cm}$.

Surface area of wooden sphere$=4 \pi \mathrm{r}^{2}$ $=\left[4 \times \frac{22}{7} \times(10.5)^{2}\right] \mathrm{cm}^{2}=1386 \mathrm{~cm}^{2}$.

Radius $\left(\mathrm{r}_{1}\right)$ of the circular end of cylindrical support$=1.5 \mathrm{~cm}$.

Height (h) of cylindrical support $=7 \mathrm{~cm}$ Curved Surface Area of cylindrical support$=2 \pi r h$. $=\left[2 \times \frac{22}{7} \times(1.5) \times 7\right] \mathrm{cm}^{2}=66 \mathrm{~cm}^{2}$.

Area of the circular end of cylindrical support $=\pi r^{2}=\left[\frac{22}{7} \times(1.5)^{2}\right] \mathrm{cm}^{2}$ $=7.07 \mathrm{~cm}^{2}$.

Area to be painted silver $=[8 \times(1386-7.07)] \mathrm{cm}^{2}$ $=(8 \times 1378.93) \mathrm{cm}^{2}=11031.44 \mathrm{~cm}^{2}$.

Cost for painting with silver color  Rs. \[(11031.44\times 0.25)=\]\[\text{Rs}\]. \[2757.8\].

Area to be painted black$=(8 \times 66) \mathrm{cm}^{2}=528 \mathrm{~cm}^{2}$.

Cost for painting with black color \[=\text{ Rs}.\text{ }\left( 528\text{ }\times \text{ }0.05 \right)\text{ }=\text{ Rs}.\text{ }26.40\].

Total cost in painting\[=\text{ Rs}.\text{ }\left( 2757.86\text{ }+\text{ }26.40 \right)\].

\[=\text{ Rs}.\text{ }2784.26\].

Therefore, it will cost \[\text{Rs}.\text{ }2784.26\] in painting in such a way.

3. The diameter of a sphere is decreased by $25 \% $. By what percent does its curved surface area decrease?

Let the diameter of the sphere be$d$.

Radius $\left(\mathrm{r}_{1}\right)$ of sphere $=\frac{d}{2}$ new radius $\left(\mathrm{r}_{2}\right)$ of sphere $=\frac{d}{2}\left(1-\frac{25}{100}\right)=\frac{3}{8} d$

CURVED SURFACE AREA $\left(\mathrm{S}_{1}\right)$ of sphere $=4 \pi \mathrm{r}_{1}^{2}$

$=4 \pi\left(\frac{d}{2}\right)^{2}=\pi d^{2}$

CURVED SURFACE AREA $\left(\mathrm{S}_{2}\right)$ of sphere when radius is decreased $=4 \pi \mathrm{r}_{2}^{2}$

$=4 \pi\left(\frac{3 d}{8}\right)^{2}=\frac{9}{16} \pi d^{2}$

Decrease in surface area of sphere $=\mathrm{S}_{1}-\mathrm{S}_{2}$

 $=\pi d^{2}-\frac{9}{16} \pi d^{2}$

$=\frac{7}{16} \pi d^{2}$

Percentage decrease in surface area of sphere $=\frac{S_{1}-S_{2}}{S_{1}} \times 100$

$=\frac{7\pi {{d}^{2}}}{16\pi {{d}^{2}}}\times 100$

$=\frac{7 \pi d^{2}}{16 \pi d^{2}} \times 100=\frac{700}{16}=43.75 \%$
