Access NCERT Solutions for Class 6 Maths Chapter 5 - Understanding Elementary Shapes

Exercise 5.5

1. Which of the following are models for perpendicular lines?

  1. The adjacent edges of a table top.

Ans:  The adjacent legs of a table top make an angle of $90^\circ $ with each other.

(Image will be uploaded soon)

Hence, they are perpendicular.

  1. The lines of a railway track.

Ans: The lines of a railway track do not meet each other. Thus, no $90^\circ $ angle is formed. Hence, the lines of railway track are not perpendicular. The following diagram shows that the lines of the railway track are not perpendicular.

(Image will be uploaded soon)

  1. The line segments forming the letter ‘L’

Ans:  The line segments that form the letter L, form a $90^\circ $ degree angle.

(Image will be uploaded soon)

Hence, they are perpendicular to each other.

  1. The letter V.

Ans:  The letter V has no right angle.

(Image will be uploaded soon)

Hence, this model is not perpendicular.


2. Let $PQ$ be the perpendicular to the line segment  $XY$.  Let $PQ$ and  $XY$  intersect in the point $A$. What is the measure of $\angle PAY$?

Ans:  We will represent the given data through a diagram.

(Image will be uploaded soon)

Since PQ is perpendicular to XY, then, $\angle PAY = 90^\circ $.


3. There are two “set-squares'' in your box.  What are the measures of the angles that are formed at their corners?  Do they have any angle measure that is common?

Ans:  The set squares form two types of angles.

(Image will be uploaded soon)

One of the set squares has angles of measure,$45^\circ $, $90^\circ $, $45^\circ $,  and the other set square has angles of measure, $60^\circ $,$90^\circ $,$30^\circ $. Thus, they have $90^\circ $ as a common angle.


4. Study the diagram. The line $l$ is perpendicular to line $m$.

(Image will be uploaded soon)

  1. Is $CE = EG$?

Ans:  Observe from the number line that $CE$ is 2 units and $EG$ is 2 units. Hence,

$CE = EG$.


  1. Does $PE$ bisect $CG$?

Ans:  As $CE = EG$, this implies that $PE$ divides $CG$ into two equal parts. Hence,

$PE$ bisect $CG$.


  1. Identify any two-line segments for which $PE$ is the perpendicular bisector.

Ans: A perpendicular bisector bisects the line segment at $90^\circ $. Observe that $PE$divides $DF$ into two segments of one unit, namely, $DE$ and $EF$. Similarly, $PE$divides $CG$ into two segments of one unit, namely, $CE$ and $EG$


  1. Are the following expressions true?

  1. $AC > FG$.

Ans:  From the figure, $AC$ measures 2 units and $FG$ measures 1 unit. Thus, $2 > 1$. So, $AC > FG$. Hence, the given relation is true.

  1. $CD = GH$

Ans: From the figure, $CD$ is 1 unit and $GH$ is 1 unit. So,$CD = GH = 1\,\,{\text{unit}}$. Hence, the given relation is true.

  1. $BC < EH$

Ans:  From the figure, $BC$ is 1 unit and $EH$ is $4$ unit. Thus, $1 < 4$. Hence, $BC < EH$. Therefore, the given relation is true.
